Cambium ePMP 4500L 5 GHz 2x2 Access Point Radio (IC) (Canada/US cord)
- SKU: C058940A164A
$975.04
- Manufacturer: Cambium Networks
- Cambium Networks ePMP 4500 Series Datasheet: Download
Product Information
Cambium Networks C058940A164A
ePMP 4500L 5 GHz 2x2 Access Point Radio (IC) (Canada/US cord)
ePMP 4500L Access Point: 2x2 MIMO AP offering high capacity and flexible connectivity with sector antennas and horn antennas.
Specifications
| Channel Width | 20 | 40 | 80 MHz |
| Proprietary Physical Layer | 2x2 MIMO/OFDMA based on 802.11ax underlying technology |
| Channel Spacing | Configurable in 5MHz increments |
| Frequency Range | Wide Band Operation 4910–6135MHz (Note: Allowable frequencies and bands are dictated by individual country regulations) |
| MAC Layer (Media Access Control) | Cambium Proprietary |
| Ethernet Interfaced | 100/1000 BaseT, rate auto negotiated, 802.3at compliant & Aux SFP port |
| Supported Powering Methods | 5V 30W PoE (included), standard 802.3at PoE Supply, or cnMatrix Tower Switch |
| Protocols Used | IPv4/IPV6, UDP, TCP, IP, ICMP, SNMPv2c, HTTPs, STP, SSH, IGMP Snooping |
| Network Management | HTTPS, SNMPv2c, SSH |
| VLAN | 802.1Q with 802.1p priority |
| Subscribers per Sector | Up to 120 |
| ARQ | Yes |
| Nominal Receive Sensitivity (w/FEC) @20 MHz Channel | MCS 0 = -93dBm to MCS 11 (1024 QAM-5/6) = -63dBm (per chain |
| Nominal Receive Sensitivity (w/FEC) @40 MHz Channel | MCS 0 = -90dBm to MCS 11 (1024 QAM-5/6) = -60dBm (per chain) |
| Nominal Receive Sensitivity (w/FEC) @80 MHz Channel | MCS 0 = -87dBm to MCS 11 (1024 QAM-5/6) = -57dBm (per chain) |
| Modulation Levels (Adaptive) | MCS 0 (BPSK) to MCS 11 (1024 QAM-5/6) |
| GPS Synchronization | Yes, via Internal GPS |
| QoS (Quality of Service) | Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority, MIR/CIR support |
| Transmit Power Range | 0 to +28dBm (combined, to regional EIRP limit) (1dB interval) |
| Antenna | 90°/120° 2x2 Sector Antenna (C050900D021B) |
| Surge Supression* | 1 Joule Integrated |
| Environmental | IP67 |
| Temperature | -30°C to 55°C (-22°F to 131°F) |
| Weight | 1.3kg (2.9lbs) |
| Dimensions (H x W x D) | 256x125x47mm (10.1x4.9x1.9in) |
| Power Consumption | 28W Maximum |
| Input Voltage | 44V to 59V |
| Sector Antenna Connection | 2 x 50 ohm, RP (Reverse Polarity) SMA Also compatible with RF Elements Twistport Adaptor for ePMP |
| GPS Antenna Connection | 1 x 50 ohm, SMA; external GPS Antenna External GPS Puck included in packaging |
| Encryption | All models: 128-bit AES (CCMP mode) |
| FCCID | Z8H89FT0062 |
| Industry Canada Cert | 109W-0062 |
| CE | See Cambium Website for Declaration of Conformity |
