Milesight 5MP AI 25X Lens 4.8-120mm Speed Dome Network Camera
- SKU: MS-C5341-X25PE
$1,959.86 $2,162.03
- Manufacturer: Milesight
- Data Sheet: Download
Product Information
Milesight MS-C5341-X25PE
5MP AI 25X Lens 4.8-120mm Speed Dome Network Camera
AI Video Analytics
- 8 intelligent VCA modes powered by AI engine, which can 8 intelligent VCA modes powered by AI engine, which can intelligently filter objects to focus on human and vehicle detection.
- People Counting technology provides high accuracy and real-time data based on AI algorithm with statistic reports.
- Face Detection function detects human faces in the monitoring scene and captures the snapshots, which greatly enhances the monitoring efficiency.
Intelligent PTZ Auto Tracking
With AI detection, Milesight Network Camera could leverage motor mechanism to perform Pan/Tilt/Zoom to track the moving human or vehicle automatically and adjust zoom status flexibly according to the target distance with the powerful optical zoom capability.
Up to 42X Optical Zoom
Embedded with optical zoom lens, the cameras’ resolution is up to 42X optical zoom which allows the user to zoom up to distant objects while still maintaining the clarity and delivering high quality video over the entire zoom range.
30fps@4K
Providing 4K HD resolution with frame rate of 30fps, the camera performs well in catching detailed image regardless of the moving speed.
Features:
- Smart IR II (Combining the High Beam and Low Beam to adjust IR intensity to fit different lighting conditions.)
- 140dB Super WDR (Excellent performance even when the ratio of the luminosity of brightest and darkest is up to 140dB.)
- 90fps High Frame Rate (Camera can easily catch images with no latency despite of the high-speed movement.)
- 0.005Lux Starlight (Deliver high detailed color images even in low light environment reaching 0.005Lux.)
- Smart PTZ Motion Detection (Pan and tilt to the position of motion detected area automatically and zoom in synchronously.)
- IR Distance up to 300m (Enabling 300 meters distinct images at night with IR LEDs.)
- 300 Preset Positions (The user can easily control the lens position via mouse to monitor interested area and set up to
- 300 preset positions for patrolling.)
- Keyboard Control (Shortcut keys for PTZ control via Milesight Keyboard.)
- Smart Stream (Bandwidth, storage and bit rate are saved with Smart Stream On, eg, H.265+ saves 70%~80% bandwidth that of H.264.)
Specifications
Specifications MS-C5341-X25PE
Camera | |
Image Sensor | 1/2.8″ Progressive Scan CMOS |
Min. Illumination | Color: 0.008Lux@F1.5 B/W: 0Lux with IR on |
WDR | 120dB Super WDR |
Shutter Time | 1/100000s~1s |
Digital Zoom | 16X |
Day/Night Mode | Day/Night/Auto/Customize/Schedule |
S/N | >55dB |
Lens | |
Focal Length | 4.8~120mm, 25X Optical Zoom |
Zoom Speed | Approx 6s (Wide-Tele) |
Field of View | H61.6°~H2.8°/D70.8°~D3.8° /V36.8°~V1.8° |
Focus Control | Auto/Semi-Auto/Manual |
Minimum Working Distance | 100/1500mm (Wide/Tele) |
Aperture | F1.5~F3.5 |
Iris Control | Auto |
PTZ | |
Pan Range/Pan Speed | 360°endless / Pan Manual Speed: 0.1°~250°/s, Pan Preset Speed: 250°/s |
Tilt Range/Tilt Speed | -5°~90°(Auto Flip) / Tilt Manual Speed: 0.1°~160°/s, Tilt Preset Speed: 160°/s |
Proportional Zoom | Support |
Preset Quantity | 300 |
Patrol | 8 Patrols, up to 48 presets each patrol |
Pattern | 4 Patterns |
Auto Tracking | Support |
Power Off Memory | Support |
Other Function | Auto Scan, Auto Home, Preset Freezing, 3D Positioning, PTZ Limits, Initial Position |
IR | |
IR Distance | Up to 200m |
IR Angle | Auto/Manual |
Video | |
Max. Image Resolution | 2592x1944 |
Primary Stream | 60Hz: 30fps@(2592x1944, 2592x1520),45fps@(2048x1536), 60fps@(1920x1080, 1280x960,1280x720) 50Hz: 25fps@(2592x1944, 2592x1520),45fps@(2048x1536), 50fps@(1920x1080, 1280x960,1280x720 |
Secondary Stream | 60Hz: 30fps@(704x576, 640x480, 640x360,352x288, 320x240) 50Hz: 25fps@(704x576, 640x480, 640x360,352x288, 320x240) |
Tertiary Stream | 60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240) 50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240) |
Video Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
Video Bit Rate | 16Kbps~16Mbps(CBR/VBR Adjustable) |
Privacy Masking | Up to 8 Areas (Mask Area and Mosaic Area are optional) |
ROI | Up to 8 areas |
Image Setting | Brightness/Contrast/Saturation/Sharpness |
Interface | |
Ethernet | 1*RJ45 10M/100M Ethernet Port |
Audio I/O | 1/1 |
Alarm I/O | 4/2 |
RS485 | Support |
Network | |
Network Storage | NAS(Support NFS, SMB/CIFS), ANR |
Protocol | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL,TLS 1.2 |
Audio | |
Audio Compression | G.711/AAC/G.722/G.726 |
Audio Sampling Rate | 8/16/32/44.1/48KHz |
Audio Bit Rate | 16~256kbps |
Two-way Audio | Support |
Intelligent Analytics | |
Video Analysis | Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed |
Face Detection & Face Attribute Recognition | Detect and capture faces, get real-time snapshots and the attributes include Age, Gender, Glasses, Mask and Cap. Support Faces Privacy Mode, the detected faces in the face detection area will be mosaic automatically. |
Object Counting & Report | Count the number of objects crossing the line, optionally human and vehicle, Support regional people counting for up to 4 detection areas |
System | |
Storage | Support microSD/SDHC/SDXC Card Local Storage, up to 1TB |
Advanced Function | BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark |
SIP/VoIP Support | Yes, Voice & Video-over-IP |
Event Trigger | Motion Detection, Network Disconnection, External Input, Audio Alarm, etc. |
Event Action | FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, PTZ Motion, HTTP Notification, etc. |
System Compatibility | ONVIF Profile G & M & S & T, API |
Working Condition | Temperature: -40℃~60℃ / Humidity: 0~95%(Non-condensing) |
Power Supply | PoE (802.3at) / AC 24V/3A±10% |
Power Consumption | 11W MAX / 27W MAX (With IR on) |
Weather Proof/Housing | Up to IP66-rated for Weather-resistant Performance / Vandal-proof IK10-rated Metal Housing(Optional) |
Heater | Support |
Wiper (Optional) | - |
Surge Protection | 6KV |
Weight | 4Kg (8.81 lbs) |
Dimensions/Weight | Φ205mmX308mm( 8.07" x 12.12" inch) |
Warranty | 2 Years / 3 Years (Optional) |
