Milesight 8 Channel 5000 Series 4K H.265 PoE NVR

(0)No Reviews yet
  • SKU: MS-N5008-PE
$1,102.07 $1,132.96

Out of Stock

 Open chat or call us for stock status

Product Information

Milesight MS-N5008-PE

8 Channel 5000 Series 4K H.265 PoE NVR

Power Decoding Capacity & Flexible Storage Options

  • The 4K NVR is equipped with solid 4K decoding and display capabilities and maximum support simultaneous viewing of 6*1080 P or 12*720P cameras.
  • Providing flexible storage options including HDD and NAS to address the needs for versatile storage.

Reliability

ANR can store video data on the camera storage card when network between IPC and NVR is disconnected and retransfer the recorded video to network NVR after network recovers

AI Video Analytics & POS Integration

  • All-in-one to Manage AI & ANPR VCA Function focus on human and vehicle detection People Counting provides high-accuracy data and statistic reports. Face Detection function supports attribute recognition. Enterprise ANPR Management makes it easy to monitor traffic.
  • POS machine information can be transferred to and displayed on the NVR.

Flexible Structure

  • U-Rack Standard supported.
  • A whole array of ports provides all necessary features for effective surveillance

Features:

  • NDAA Compliance (The fully NDAA compliant products are well suited for Government, defense and a range of projects subject to the NOAA )
  • 8/16-CH Input & 8/16*PoE Ports (8/16 channels are supported, ana PoE ports design provides just one steo to connect.)
  • H 265 (H 265 allows to cut down 70%c 80 o bdndwidth while ensuring the high Quality of imapes compared with H 264.)
  • Dual Stream Recording (Supporting Primary Stream and Secondary Stream recording simultaneously )
  • HTMLS Streaming Ready (Support previewing the video via all major browsers without plup-in when Video Codec is set to H.265.)
  • Auto Backup (The latest 24 hours' video will De automatically backed up to USB Port Devices or NAS after setting up the Dackup.

Specifications

Specifications MS-N5008-PE

Video/Audio Input
Network Video Input8-CH
Bandwidth Incoming80Mbps
Bandwidth Outgoing50Mbps
HDMI Output1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI Supports Audio Output
VGA Output1-CH, Resolution: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Dual StreamSupport
Recording Resolution8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/D1/VGA/CIF/QCIF
Synchronous Playback1*(30fps @8MP), 2*(30fps @6MP), 2*(30fps @5MP), 3*(30fps @4MP),4*(30fps @3MP),6*(30fps @1080P), 8*(30fps @720P)
Video CompressionH.265+/H.265(HEVC)/H.264+/H.264
Audio CompressionG.711/AAC/G.722/G.726
Sample Rate8KHz/16KHz
SATA2*SATA HDD(3.5”)
CapacityUp to 20TB capacity for each HDD
Recording TypeContinuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Snapshot TypeN/A
Playback TypeGeneral Playback, Event Playback, Tag Playback, Split Playback, Picture Playback
BackupVideo Backup, Image Backup
ProtocolIPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS
Network Interface1*RJ45 10/100/1000Mbps
USB Interface2*USB 2.0
Audio Input/Output1*RCA/1*RCA
Alarm Input/Output4-CH/1-CH
Interface8*RJ45 10/100Mbps
Power Output≤200W
Supported StandardIEEE 802.3af/at
CompatibilityONVIF, API
Advanced FunctionANR
ANPRSupport
Video AnalysisRegion Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed
Keyboard ControlMilesight Keyboard (MS-K01)
Power SupplyAC 100V~240V 50Hz~60Hz
Consumption≤9W(Without HDD, without enabling PoE)
Working ConditionsTemperature: -10℃~55℃ / Humidity: 10%~90%
Dimensions

Rack Mountable Chassis (1.0U Standard) 380mm(W)X317.6mm(D)X51.8mm(H)

14.96 x 12.50 x 2.03 inch

Weight2.6Kg (5.73 lbs)
Warranty3/5 Years
