Poynting AT-OMNI39-GSM
Poynting 2db GSM Operating Frequency: 790 – 960, 1710 – 2170 and 2500 – 2700 MHz Bands
This is an aesthetically pleasing all-band cellular antenna for general indoor and outdoor cellular applications. The linear polarised antenna has a compact design and magnet mounting making it suitable for mobile applications as well. It is ideal for machine to machine (M2M) applications that are communicating through the mobile network (GPRS / EDGE / 3G /HSPA/LTE). This antenna exceeds the performance of a standard monopole for the following reasons: It is ground plane independent, it uses high qualitylow-loss cable, it is a dipole, not a monopole.
Specifications
Specifications AT-OMNI39-GSM
Electrical
| Frequency Bands | 790 - 960 MHz |
| Gain (Max) | 2.3 dB |
| VSWR | <2.5:1 |
| Feed Power Handling | 10 W |
| Input impedance | 50 Ohm (nominal) |
| Polarisation | Linear Vertica |
| Cable loss | Optional Cable dependant |
| DC Short | Yes |
Environmental
| Wind Survival | Magnetic Mount. Not for vehicle use |
| Temperature Range (Operating) | -40°C to +70°C |
| Environmental Conditions | Outdoor/Indoor |
| Operating Relative Humidity | Up to 98% |
| Storage Temperature | -40°C to +70°C |
Mechanical
| Dimensions (l x w x d) | 150 mm x 60 mm x 40mm |
| Weight | 110 g |
| Colour | Black |
