Tycon Power Voltage Converter 18-36VDC Input, 24VDC @ 3A 70W Regulated Output
- SKU: TP-VRHP-2424
$49.83 $110.36
- Manufacturer: Tycon Power
- Data Sheet: Download
Product Information
Tycon Power TP-VRHP-2424
DC Voltage Converters 18-36VDC Input, 24V 2.9A 70W Regulated Output
DC Input Voltage Range: 18V to 36VDC
DC Voltage Output: 24VDC @ 2.9A
Maximum Power: 70W
The TP-VRHP series of DC to DC converters offer high output voltage conversion in a compact metal enclosure. They have wire terminal inputs and outputs for maximum flexibility. The units come with DIN rail adapters for DIN rail mounting. They provide power output up to 250W.
Features:
- Voltage Converter
- High Output, Short Circuit Protected
- Metal Enclosure, DIN rail mounting
- Industrial Temperature Operation
- Most Models Isolated Input to Output
- Low Voltage Disconnect
Applications:
- Security Systems
- Remote Power Systems
- Telecom Applications
- Wireless Base Stations
Specifications
Specifications TP-VRHP-2424
| DC Input Voltage Range | + or - 18V to 36VDC |
| DC Voltage Output | 24VDC @ 2.9A |
| Maximum Power | 70W |
| Efficiency | >85% |
| Load / Line Regulation | 5% / 1% |
| Ripple / Noise | 2% / 5% |
| Isolation Voltage / Ohms | 1500VDC Min. / 100M Ohms Min |
| Wire Gauge | 12AWG Max |
| Protections | Short Circuit, Overvoltage, Overload |
| Operating Temperature | -22°F to 149°F (-30°C to +65°C) |
| Operating Humidity | 0 to 90% RH |
| Size | 5.24 x 3 x 1.5” (133x75x38mm) |
| Weight | 0.65 lbs (298g) |
